【Dual-Lead Worm Gear Reducer】Adjustable Backlash Technology for High-Precision Positioning & Maximum Rigidity

The RGL Dual-Lead Worm Gear Reducer is developed for high-end automated and precision machinery that demands exceptional positioning accuracy, minimal backlash, and long-term geometric stability. The core of this series lies in its advanced "dual-lead variable tooth thickness worm" technology, where the left and right tooth profiles of the worm feature different leads.

This creates a gradual change in tooth thickness along the axial direction. When minimal wear occurs after prolonged, high-intensity use, engineers can perfectly and easily readjust and eliminate meshing backlash simply by shifting the worm's axial position. This unique advantage keeps the machinery operating at a "near-zero backlash" state while maintaining the large torque and structural rigidity of worm drives.



  • Adjustable Backlash for Long-Term Accuracy: Easily compensates for wear gaps via simple axial adjustments, significantly extending the service life of high-precision operations.
  • Excellent Repeat Positioning Precision: Tight tooth meshing and superb dynamic response make it ideal for precise positioning under frequent forward-reverse servo control.
  • High Rigidity & Ultra-Smooth Drive: Crafted from premium alloy steel and specialized high-tin bronze with ultra-precision grinding, ensuring low noise, low heat, and maximum drivetrain stability.



【Applications】 Widely applied in machine tool 4th-axis rotary tables, precision indexing drives, robotic joint actuators, printing/coating alignment mechanisms, and high-end CNC automation control systems.
