【Single-Stage Horizontal Worm Gear Reducer】Smooth Operation & Heavy-Duty Reliability for Foot-Mounted Drives

The RGL Single-Stage Horizontal Worm Gear Reducer is engineered for industrial environments requiring horizontal installation, right-angle turns, and high reduction ratios. Featuring a robust, one-piece foot-mounted cast iron casing, this series securely attaches to the machinery chassis, delivering superior shock absorption and stress dispersion to ensure the base remains displacement-free under continuous heavy duty.

The internal mechanism comprises premium alloy steel worms and specialized copper-alloy worm wheels. Precision-machined for optimal sliding mesh, they deliver ultra-quiet and smooth power transmission, along with a reliable "self-locking feature" at high ratios to provide an extra layer of passive safety.



  • Robust Foot-Mounted Design: Provides simple horizontal installation with a low center of gravity and high vibration resistance, easily handling heavy load outputs under substantial torque.
  • 90-Degree Right-Angle Layout: The 90-degree intersection of input and output shafts allows for flexible lateral and longitudinal space adjustments, optimizing machine configurations.
  • Sealed Enclosure & Premium Seals: High-wear dual-lip oil seals paired with a fully enclosed lubrication system prevent dust ingress and oil leakage, keeping the operation environment clean.



【Applications】 Perfectly suited for heavy-duty conveyors, metallurgical machinery, packaging sorting systems, woodworking machinery, and automated production lines.
