【Single-Stage Horizontal Direct-Coupled Gear Motor】High-Rigidity Foot Mount & Modular Motor Coupling

The RGL Single-Stage Horizontal Direct-Coupled Gear Motor is engineered for conveyor and driving systems that demand exceptional structural stability, flexible motor options, and easy on-site maintenance. Equipped with a standard IEC motor flange interface, it couples directly with standard, inverter, or brake motors, eliminating traditional coupling space and alignment time.

The structure features an integrated, full-flat foot mount designed to resist the counter-forces of high-torque operation. Internal reduction gears undergo precision machining and advanced hard-surface grinding, achieving a superior transmission efficiency of over 95% for quiet and energy-saving performance.



  • Standard IEC Direct Flange: Eliminates external couplings, allowing modular motor replacement or upgrades at any time, simplifying maintenance and minimizing downtime.
  • Integrated Full-Flat Foot Mount: The one-piece cast iron foot mount provides outstanding rigidity and vibration resistance, ensuring the drive remains completely stable under frequent start-stop cycles.
  • High Efficiency & Shock Resistance: Precision-ground gears ensure flawless meshing, reducing operating noise and heat generation while significantly extending the lifespan of lubricants and internal components.



【Applications】 Widely used in heavy-duty conveyor belts, packaging machinery, automated food processing lines, linear drive mechanisms, and factory automation drive systems.
